Size Main dimensions Reference data
DN(mm) PNS(inch) L D D1 D2 f b Z-d Do H
PN1.0MPa
15 1/2 140 95 65 45 3 15 4-14 140 90
20 3/4 140 105 75 55 3 17 4-14 140 100
25 1 150 115 85 65 3 17 4-14 180 105
32 5/4 165 140 100 75 3 19 4-18 180 120
40 3/2 180 150 110 85 3 19 4-18 225 140
50 2 200 165 125 100 3 21 4-18 225 150
65 5/2 220 185 145 120 3 21 4-18 360 160
80 3 250 200 160 135 3 21 8-18 360 215
100 4 280 220 180 155 3 23 8-18 420 240
125 5 320 250 210 185 4 24 8-18 520 250
150 6 360 285 240 210 4 26 8-23 520 290
200 8 400 340 295 265 4 26 8-23 240 340
250 10 450 395 350 320 4 28 12-23 240 380
Beijing Yichuang Valve Manufacturing Co., Ltd covers an area of 30, 000 square meters, registered capital of 51.18 million yuan, with about 300 staffs and more than 50 professional and technical personnel.
We are a professional manufacturer of valves for more than 14 years experiences. The products include gate valve, globe valve, check valve, throttle valve, ball valve, butterfly valve, etc. Standards as GB, ANSI, API, BS, JIS, DIN, etc. Products are widely applied in electric power, petroleum, chemical, fertilizer, metallurgy, papermaking, pharmaceutical and other industries. The products have won certificates of API, ISO etc. Hope we can have a chance to cooperate with your honored company.
