Y Type valves are available in three bonnet designs. The first design is the Bolted Bonnet, with male-female joint, spiral wound gasket, made in F304L/graphite. Ring joint gasket are also available on request. The second design is the welded bonnet, with a threaded and seal welded jiont. On request a full penetration strength welded joint is available. The third design is the pressure seal bonnet, with a threaded and pressure seal bonnet joint. The Y Type valves are available in globe and check design configurations.
Design Feature:
* Full Port or Conventional Port
* Piston and ball check
* Spring available on request
* Loose solid disc
* Two plece self-aligning packing gland
* Integral back seat
* Outside Screw and Yoke (OS & Y)
* Bolted bonnet with spiral- wound gasket, threaded and seal welded bonnet or threaded and pressure seal bonnet
* Socket weld ends to ASMB B16.11
* Screwed Ends (NPT) to ANSI/ASMB B1.20.1
Size:
1/2"~2"
Rating:
Class800, 2500
Materials:
A105, F11, F22, F304, F316, F5, F51, F53 or Equivalent
Actuation:
Handwheel
