| Prod Model: |
Q41F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Pressure: |
150lb--300lb |
| Size: |
1''--10'' |
| Channel: |
Straight Through Type |
| Structure: |
Floating Ball Valve |
| Type: |
Floating Ball Valve |
| Application: |
Pipe Construction |
| Connection Form: |
Flange/Butt-Welded/ |
| Material: |
Foeged Steel/ Cast Steel/Stainless Steel |
Product Description
API 6D Cast Steel 2-PC Floating Ball Valve:
A. Size of 1/2 inch to 10 inch.
B. Pressure from class 150 to class 600.
C. End connections by RF/RTJ/butt-weld, socked weld.
D. Designed and tested according to API 598/6D, 2-piece bolted body design.
E. Fire safe to API-607, anti-static and NACE MR-01-75.
F. Material: WCB, CF8, CF8M, LCC, LCB etc.
G. Full bore and reduced bore
|
NO |
Part Name |
Material |
|
1 |
Left body |
A105,A350-LF2,A182-F304,F316,F304L,F316L,F321,F51,F53,ALLOY-20 |
|
2 |
Seat |
PTFE,RPTFE,PEEK,PPL,POM, KARBATE,NYLON,MOLON,DEVLON |
|
3 |
Ball |
A105+ENP,A350-LF2+ENP,A182-F,F6,F304,F304L,F316,F316LF321 |
|
4 |
O-ring |
NBR,VITON |
|
5 |
Gasket |
FlexbleGraphite+304,FlexbleGraphite+316,PTFE |
|
6 |
Bolt |
A194-2H,2HM,8,8M |
|
7 |
Nut |
A193-B7,B7M,B8,B8M |
|
8 |
Right body |
A105,A350-LF2,A182-F304,F316,F304L,F316L,F321,F51,F53,ALLOY-20 |
|
9 |
Small spring |
SS304,SS316 |
|
10 |
Small Ball |
SS304,SS316 |
|
11 |
Thrust Washer |
PTFE |
|
12 |
Stem |
1045+ENP,A182-F6,F304,F316,F304L,F316L,F321 F51,F53,ALLOY-20 |
|
13 |
Packing |
Flexible Graphite,PTFE |
|
14 |
Gland |
A182-F6,F304,F316,F304L,F316L,F321,F51,F53,ALLOY-20 |
|
15 |
Gland flange |
A351-CF8 |
|
16 |
Lever |
A216 WCB +1020 |
|
17 |
Stop Screw |
1035 |
|
18 |
Limited Plate |
1025,SS |
|
19 |
Screw |
A193-B7,B8 |
|
|
|
|
Zhejiang xiongtai valve manufacturing Co., Ltd., eattablished in 1998 and situated in Oubei Yongjia, a China hometown of pump and valve is a plant integrating R&D, production, sales and survi of valves and has abundent strengths and plentiful production experience with a staff of about 200 involving several steel valve and steel valve etc., and has obtained certifications of ISO9001, API6D, TS and so on.
Zhejiang xiongtai valve manufacturing Co., Ltd., eattablished in 1998 and situated in Oubei Yongjia, a China hometown of pump and valve is a plant integrating R&D, production, sales and survi of valves and has abundent strengths and plentiful production experience with a staff of about 200 involving several steel valve and steel valve etc., and has obtained certifications of ISO9001, API6D, TS and so on.
