Main Parts and materials:
Parts Name | Material |
Body,Bonnet | A216WCB | A351,CF8,CF8M,CF3,CF3M | A3521LCB,LCC | A216 WCB | A351 CF8M |
Stem | A182 F6a | A182 F304,316 | A182 F6a | A182 F304 | A182 F304 |
Sealing Ring | PTFE ,RPTEE,NYLON,MOLON,DELRIN or PEEK |
Seat | A105+HCr/ENP | A182,F304,316 | A182 F6a | A105+HCr/ENP | A182,F316 |
Back Seat | A105+HCr/ENP | A182,F304,316 | A182 F6a | A105+HCr/ENP | A182,F316 |
Ball | A105+HCr/ENP | A315,CF8,CF8M,CF3,CF3M | A352LCB,LCC+ENP | A105+HCr/ENP | A351CF8M+ENP |
Standards:
Design and Manufacturer | Face to Face | Flange End | Inspection |
API 6D,BS5351 | ANSI B16.10 | ANSI B16.5 | API 598 |
Test Pressure
Test Item | Shell Test | Seal Test | Back Seal Test | Air Seal Test |
Medium (MPa) | water | Air (MPa) |
Pessure Class | 150 | 3.1 | 2.2 | 2.2 | 0.5-0.7 |
300 | 7.8 | 5.6 | 5.6 |
600 | 15.3 | 11.2 | 11.2 |
900 | 23.1 | 16.8 | 16.8 |
