Resilient Seated Gate Valve, Flanged Ends, PN10/16.
Ductile Iron Body and Bonnet, Stainless Steel Shaft, Ductile Iron Disc with EPDM coated, inside/outside Fusion Bonded Epoxy.
Designed as per BS4090/BS5153. Flanged according to ANSI/BS/DIN/ISO at buyer's option
*This valve is designed and manufactured |
according to BS5153 |
|
|
*Working presssure: 16kg/cm2 |
|
*Shell test pressure: 24kg/cm2 |
|
*Seat test pressure: 18kg/cm2 |
|
*Media: Water, neutral oil |
|
|
*Working temperatu |
temperature: 0.6-52oC |
re: 0.6-52oC |
|
*External and internal coating: 100% |
|
fusion-bonded epoxy |
|
|
*Flange drilled according to BS4504 Table |
10/11, 16/11; EN1092 PN10, PN16 |
|
