Diaphragm ValveDescription:Diaphragm valves are used on shut-off and throttling service for liquids, slurries and vacuum/gas.
There are two types of diaphragm valves:
Weir: The Weir Diaphragm valve can be used for either off/on and throttling services
Straightway: named also Straight-Thru is only used for on/off services.
Technical SpecificationFlange connection dimension: GB/T 17241.6-1998, GB/T 9113.1-2000
Nominal pressure: PN1.0MPa, PN1.6MPa
Nominal diameter: DN50
~600mm
Body material: Cast Iron
|
PN |
work pressure |
DN |
L |
D |
D1 |
N-φd |
F |
H1 |
H2 |
D0 |
weight |
|
|
|
mm |
inch |
|
|
|
|
|
|
|
|
|
|
1.0 |
1.0 |
15 |
1/2" |
125 |
95 |
65 |
4-14 |
2 |
105 |
116 |
100 |
4.5 |
|
20 |
3/4" |
135 |
105 |
75 |
4-14 |
2 |
117 |
128 |
100 |
4.5 |
|
25 |
1" |
145 |
115 |
85 |
4-14 |
2 |
121 |
135 |
120 |
5 |
|
32 |
1-1/4" |
160 |
140 |
100 |
4-18 |
2 |
132 |
150 |
120 |
7 |
|
40 |
1-1/2" |
180 |
150 |
110 |
4-18 |
3 |
156 |
176 |
140 |
9 |
|
50 |
2" |
210 |
165 |
125 |
4-18 |
3 |
169 |
195 |
140 |
14 |
|
65 |
2-1/2" |
250 |
185 |
145 |
4-18 |
3 |
200 |
236 |
200 |
19 |
|
80 |
3" |
300 |
200 |
160 |
4-18 |
3 |
216 |
256 |
200 |
29 |
|
100 |
4" |
350 |
220 |
180 |
8-18 |
3 |
270 |
322 |
280 |
45 |
|
125 |
5" |
400 |
250 |
210 |
8-18 |
3 |
338 |
406 |
320 |
62 |
|
150 |
6" |
460 |
285 |
240 |
8-22 |
3 |
384 |
464 |
320 |
80.5 |
|
0.6 |
0.4 |
200 |
8" |
570 |
340 |
295 |
8-22 |
4 |
518 |
638 |
400 |
146 |
|
250 |
10" |
680 |
395 |
350 |
12-22 |
4 |
598 |
734 |
500 |
240 |
|
300 |
12" |
790 |
445 |
400 |
12-22 |
4 |
698 |
778 |
500 |
334 |
|
350 |
14" |
900 |
505 |
460 |
16-22 |
4 |
723 |
883 |
500 |
371 |
|
0.25 |
400 |
16" |
1000 |
565 |
515 |
16-25 |
4 |
868 |
1078 |
640 |
584 |
