Specifications
1)Body: DIN17245
2)Stem: ASTM A182 F6a
3)Wedge: DIN 17245
4)Bonnet: DIN 17245
5)Suitable medium: Water, oil, vapour etc.
6)Actuator: Manual
7)Nominal size: PN10, DN15mm-300mm
PN16, DN15mm-600mm
PN25, DN15mm-600mm
PN40, DN15mm-600mm
PN63, DN40mm-400mm
8)Nominal pressure: 1.0/1.6/2.5/4.0/6.3MPa
9)Strengh testing: 1.5/2.4/3.8/6.15/9.75MPa
10)Seal test: 1.1/1.8/2.8/4.51/7.15MPa
Standard
Design and manufacture: DIN3352 BS EN1984
Face to face: DIN3202, BS EN558-1
Flange standard: DIN2543, DIN2544, DIN2545, DIN2546
Inspection standard: DIN 3230 BS EN12569
