DIN Resilient Seat OS&Y Gate Valve F4
DIN Resilient seat OS &Y gate valves is used to turn on or off the pipelines, suitable medium are water, oil, vapor, etc. It can be used in chemical industry, pharmaceutical industry etc.
Specifications
1)Nominal pressure: 1.0MPa/1.6MPa
2)Body: Ductile iron
3)Bonnet: Ductile iron
4)Disc: Ductile iron
5)Stem: Stainless steel
6)Shell test: 1.5MPa/1.4MPa
7)Seal test: 1.1MPa/1.76MPa
8)Actuator: Manual
Standard
Design standard: DIN3352F4
Face to face: DIN3202
Flange standard: DIN2501
