Norminal diameter: DN15-100
Pressure range: 0-40bar
Medium Temp: -10c^+180c
Environment Temp: -10c^+60c
Body material: Stainless steel, cast steel
Sealing: PTFE
Body of actuator: Aluminium alloy
Control pressure: 3-8bar
Feature: Double acting, Single acting
Connection: Screw thread. Clamp. Welding.
|
Diameter |
Size(mm) |
|
mm |
inch |
PN |
D |
L |
H1 |
Double acting pneumatic |
Single acting pneumatic |
Electric |
|
H2 |
A1 |
H2 |
A2 |
H2 |
A3 |
|
15 |
1/2 |
16/40 |
95 |
150 |
98 |
96 |
145 |
115 |
195 |
105 |
72 |
|
20 |
3/4 |
16/40 |
105 |
160 |
103 |
96 |
145 |
115 |
195 |
105 |
72 |
|
25 |
1 |
16/40 |
115 |
180 |
114 |
115 |
158 |
137 |
217 |
102.5 |
160 |
|
32 |
1-1/4 |
16/40 |
135 |
200 |
122 |
115 |
158 |
137 |
217 |
102.5 |
160 |
|
40 |
1-1/2 |
16/40 |
145 |
220 |
127 |
137 |
177 |
147 |
258 |
102.5 |
160 |
|
50 |
2 |
16/40 |
160 |
240 |
146 |
137 |
177 |
147 |
258 |
102.5 |
160 |
|
65 |
2-1/2 |
16/40 |
180 |
260 |
165 |
147 |
196 |
165 |
299 |
126 |
196 |
|
80 |
3 |
16/40 |
195 |
280 |
180 |
165 |
225 |
182 |
348.5 |
126 |
196 |
|
100 |
4 |
16/40 |
215 |
320 |
202 |
182 |
273 |
199 |
397 |
148 |
255 |
|
125 |
5 |
16/40 |
245 |
380 |
243 |
199 |
304 |
221 |
473 |
148 |
255 |
|
150 |
6 |
16/40 |
280 |
440 |
261 |
221 |
372 |
280 |
601 |
148 |
255 |
|
200 |
8 |
16/40 |
335 |
550 |
332 |
280 |
461 |
383 |
940 |
162 |
310 |
