| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
| Model | HLF02 04D | HLF02 08D | HLF02 16D | HLF02 24D | HLF02 32D | HLF02 04A | HLF02 08A | HLF02 16A | HLF02 24A | |
| Output Torque | 4Nm | 8Nm | 16Nm | 24Nm | 32Nm | 4Nm | 8Nm | 16Nm | 24Nm | |
| Max Baffle Plate size | 1m | 2m | 4m | 6m | 6m | 1m | 2m | 4m | 6m | |
| Time for Rotating 90° | 35S | 30S | 80S | 125S | 140S | 35S | 30S | 80S | 125S | |
| Modulating Scope | 0~90° (In 5°Incerments) | |||||||||
| Operating Voltage | 24VAC/24VDC AC220V~230V 50/60Hz AC110V 50/60Hz | |||||||||
| Power Rating | 4W | 3.9W/4.8W | 4W | 2.5W | 4W/4.8W | |||||
| Control Input | 2/3( Flocating Points) | 0~10VDC 4~20mA | ||||||||
| Position Output | 0~10VDC 4~20mA | |||||||||
| Driving Shafts | 8~32Nm Cylinder shaft size: φ20mm; Square shaft size: 16x16mm | |||||||||
| 4Nm Cylinder shaft size: φ16mm; Square shaft size: 12x12mm | ||||||||||
| Housing | ABS engineering plastic | |||||||||
| Ambient Temperature | Operation:-20~+50°C Storage:-40~+80°C | |||||||||
| Relative Humidity | 0~90%RH | |||||||||
| Protection | IP54 | |||||||||
| Noise Grade | 45Db (A) | |||||||||
| Net Weight | 8~32Nm: 1.1kg 4Nm :0.7kg | |||||||||
| Certificate | CE, ISO9001 | |||||||||
| Usage life | 60,000 | |||||||||
| Prod Model: | Hlf02-08dn |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: | Industrial Usage |
