1. Standard: JIS
2. Type: Gate valve, globe valves, angle valves, swing check valves
Angle storm balves, air vent, can water filter
3. Body: Cast steel, cast iron
4. Disc: Cast steel, cast iron, bronze
5. Seat: Brass, cast steel
6. Stem: Stainless steel, brss
7. Pressure: 5K, 10K, 16K
8. Size: 2''-12''
9. Packaging: Export poly wooden cases or as per customers' requirements
10. Deliver time: 35 days after order conformed
11. Payment: By T/T or L/C
12. Application: Shipbuild industry etc.
| parts name | material |
| body | grey cast iron |
| wedge disc | grey cast iron+NBR+EPDM |
| bonnet | grey cast iron |
| stem | 2Cr13 |
| Nominal DN | dimension |
| L | H |
| 50 | 178 | 732 |
| 65 | 190 | 773 |
| 80 | 203 | 820 |
| 100 | 229 | 870 |
| 125 | 254 | 915 |
| 150 | 267 | 1003 |
| 200 | 292 | 1110 |
| 250 | 330 | 1263 |
| 300 | 356 | 1360 |
| 350 | 381 | 1550 |
| 400 | 406 | 1610 |
| 450 | 432 | 1900 |
| 500 | 457 | 1938 |
| 600 | 508 | 2120 |
