V TYPE BALL VALVE
USAGE
The V type ball valve is suitable for use on various pipelines of Class150~Class300. According to different user requirements, the V type ball valve can be used for two purposes. One is it can be for controlling parameters such as flow rate of medium in the pipeline. The V type ball valve for cut-off purpose can adopt different driving modes such as manual operation, worm and worm gear transmission, pneumatic operation and electric operation. The V type ball valve for control purpose adopt the driving modes such as pneumatic operation and electric operation. By using different materials, the V type ball valve can be used for various media such as water, steam,oil, liquefied gas, coal gas, nitric acid, acetic acid, oxidizing medium, urea and etc.
The connection ends of V type ball valve can be wafer or flange.
STRUCTURAL FEATURES
1. The V type ball valve adopts disc or cylindrical spring loaded moveable metal seat structure provided with compensation character, so no problems such as blocking or release of V type ball valve and seat will occur. The sealing is reliable and the service life is long.
2. The V type notch of the ball plays the shearing function between the metals, so the valve is especially suitable for media of high viscosity, containing fiber, solid granules slurry and paper pulp.
3. According to different service conditions, the metal seated ball and seat sealing face can be subjected to various advanced technologies such as nickel-base alloy(HRC≥60)spray welding, tungsten cobalt alloy(HRC≥70)HVOF coating, suitable for various server service conditions.
4. When the valve is fully opened, the flow is high and pressure loss is low, and the media will not deposit in the middle cavity of valve. The valve has flow characteristics of equal percentage, and the V type ball valve for control purpose has a wide adjusting range with the maximum adjusting ratio of 100:1. In addition, the valve is also provided with precise control and reliable positioning functions.
5. Compact structure, strong adaptability. The V type ball valve for cut-off purpose has good sealing performance and can replace various valves such as gate valve, globe valve, ordinary ball valve and etc.
The connection ends of V type ball valve can be wafer or flange.
| Design Standards | API 6D/ API 608/BS 5351/DIN3357 |
| Pressure-Temperature Rating | ASME B16.34/BS 5351 |
| Face to face | ASME B16.10/ API 6D /DIN EN558.1 |
| Flange Ends | ASME B16.5(MSS SP-44)/ASME B 16.47/BS 1560/DIN EN1092.1 |
| Butt-Welding Ends | ASME B16.25/DIN EN12627 |
| Socket-Welded Ends | ASME B16.11 |
| Threaded Ends | ASME B1.20.1 |
| Inspection and Test | API6D/API 598/BS 5146/DIN EN12266.1 |
| Operation | Hand wheel, Gear, Pneumatic, Electrical etc. |
| Norminal diameter | 1/2"~48",DN15~DN1200 |
| Pressure rating | CLASS150~ CLASS 2500,PN10-PN420 |
| Material | WCB,WCC, LCB, LCC, C5, WC6, WC9, CF8, CF8M, CF3, CF3M,
A105, LF2, LF3, F304, F316, F304L, F316L etc. |
