Applicable Medium: High pressure fluid, gas etc.
Medium Temperature: -5 ~ 180º C
Action Mode: Pilot-operated
Working Pressure: 6~100bar (under normally closed conditions)
Valve Material: Stainless Steel (precision casting)
Seal Material: PTFE
Features
1. The applicable media for YSI high pressure solenoid valve are limited to the fluid, high pressure gas etc.
2. It adopts the pilot-operated action mode and has stainless connection deaden.
3. It is made in accordance with the standard of high quality magnetic material of Sino-American joint venture and the standard of working pressure PN2.5MPA.
4. The valve body is made of stainless steel flange (ss304j precision casting).
5. This valve with advanced structure and special technique features stable property and high reliability.
|
Model |
Connector G |
Diameter |
CV Value |
Length (mm) |
Height (mm) |
Working Pressure(bar) |
|
YSI-15 |
1/2 |
15 |
4.2 |
82 |
140 |
6~100 |
|
YSI-20 |
3/4 |
20 |
7 |
90 |
153 |
|
YSI-25 |
1 |
25 |
12 |
100 |
162 |
|
YSI-32 |
11/4 |
32 |
22 |
110 |
170 |
6~80 |
|
YSI-40 |
11/2 |
40 |
30 |
130 |
185 |
|
YSI-50 |
2 |
50 |
48 |
150 |
201 |
|
YSI-15JF Stainless Flange |
1/2 |
15 |
4.2 |
120 |
175 |
6~100 |
|
YSI-20JF Stainless Flange |
3/4 |
20 |
7 |
130 |
188 |
|
YSI-50JF Stainless Flange |
1 |
25 |
12 |
140 |
220 |
|
YSI-32JF Stainless Flange |
2 |
32 |
22 |
160 |
218 |
6~80 |
|
YSI-40JF Stainless Flange |
11/2 |
40 |
30 |
170 |
232 |
|
YSI-50JF Stainless Flange |
2 |
50 |
48 |
200 |
258 |
Our factory was founded in 1965. Through 50 years of development, we have become one of the most professional manufacturers of solenoid valves.
With great confidence in our products and services, our factory has obtained orders from all over the world. Our customers are from Australia, USA, Spain, Mexico, Saudi Arabia, Ireland, German, France and Canada.
Our factory manufactures the products as per the ISO9001 quality management system and CE, RoHS, TUV, FDA standards. Our factory has been equipped with advanced processing machines, including CNC digital controlled apparatus. We have a strong R&D team to research and customize products to cater various requirements of customers.
We have been persisting in providing our customers with superior quality products and perfect services by constantly innovating and self-improvement. Customer satisfaction is our unswerving pursuit.
