| Prod Model: |
XT-H11H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Port Size: |
3/8"-21/2" |
| Pressure: |
150lb-1500lb |
| Connection Form: |
Flange |
| Structure: |
Swing |
| Function: |
Nrvg Silence |
| Application: |
Household Usage |
| Material: |
Carbon, Stainless Steel and Other Materials |
Product Description
Standard Material Specifications
NO. Part NameCS to ASTMAS to ASTMSS to ASTM
Type A105Type F22Type F304(L)Type F316(L)
1BodyA105A182 F22A182 F304(L)A182 F316(L)
2Piston DiscA276 420A276 304A276 304(L)A276 316(L)
3GasketCorrugated SS + graphiteSS + PTFE
4BonnetA105A182 F22A182 F304 LA182 F316(L)
5NameplateSS
6BoltA193 B7A193 B16A193 B8MA193 B8M
7BallA182 F304A182 F304A182 F304A182 F304
Suitable MediumW. O. G. EtcW. O. G. EtcHNO3, CH3OOH etc
Suitable Temperature-29degree~425degree-29degree~550degree-29degree~180degree
Note: Other materials are available upon request.
Zhejiang xiongtai valve manufacturing Co., Ltd., eattablished in 1998 and situated in Oubei Yongjia, a China hometown of pump and valve is a plant integrating R&D, production, sales and survi of valves and has abundent strengths and plentiful production experience with a staff of about 200 involving several steel valve and steel valve etc., and has obtained certifications of ISO9001, API6D, TS and so on.
