| Prod Model: |
Q41 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
1''--4'' |
| Pressure: |
150lb--600lb |
| Connection Form: |
Flange |
| Channel: |
Straight Through Type |
| Structure: |
Fixed Ball Valve |
| Type: |
Fixed Ball Valve |
| Application: |
Pipe Consyruction |
| Material: |
Forged Steel |
Product Description
1. 2 Pieces Body construction
2. Graphite reinforced PTFE or PEEK as seat (PEEK can gain better performance under high temperature and high pressure condition, normally used for 1500LB ball valve).
3. Blow-out proof stem;
4. Fire safe construction (PTFE body seal with secondary Metal to metal seal)
5. Anti static device
6. Stopper device
7. ISO 5211 Mounting pad
8. Socket weld ends: ASME B 16.11
Threaded ends: ANSI/ASME B 1.20.1
Butt-welded ends: ANSI B16.25
Flange ends: ANSI B16.5
9. Forged Steel Ball Valves conform to BS5351 and MSS SP-118. Each valve is inspected and tested in accordance with API 598, and marked per MSS SP25.
10. Main materials: A105, LF2, F5, F22, F304, F316, F347, F321, F51, Monel, 20# Alloy
