| Prod Model: |
Q41 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
Dn15-1400 |
| Nominal Pressure: |
600lb |
| Connection Form: |
Flange |
| Channel: |
Straight Through Type |
| Structure: |
Fixed Ball Valve |
| Type: |
Fixed Ball Valve |
| Application: |
Pipe Construction |
| Material: |
Forged Steel |
Product Description
？
Product Description
Technical descriptions:？
Nominal diameter: ？Regular bore DN15 to DN 1400 (1/2" to 56");？
Nominal Pressure: PN 16 to PN 64 /？ANSI Class 150 to Class 800;？
Working temperature: -29 centigrade to 200 centigrade (-20 fahrenheit to 392 fahrenheit )
Service: District heating hot water, natural gas, oil, steam, petrochemical. etc.？
Operate actuator: Lever, gear (Vertical /？Horizontal), pneumatic /？electrical
Reduced port as below: DN15-DN150 ( 1/2" to 6")
DN200 to DN1400 ( 8" to 56")
Benefits:？
1？International Certificates &？Standards;？
2？Designed for district heating system, heat transfer piping, oil pipelines and gas industry application
3？Same lifetime as the pipeline system;？
4？Maintenance-free, no adjustment or lubrication with no running costs;？
5？Bi-Directional valve.？
Main Characteristics:？
1？One-piece welded body &？End piece connection pipe (Connection dimension to ASTM /？EN /？KS /？JIS /？GOST Standard. etc will be available.？
2？Bubble tight excellent sealing with PTFE+C seats.？
3？Pre-loaded seat springs ensure leak-tight at low pressure and reduce valve operational torque.？
4？Anti blow-out stem.？
5？Double O-rings ensure the stem sealing and are replaceable.？
6？Stem dry bearing, metal with PTFE coating having self-lubricating capabilities. (Additional lubricant unnecessary.？
Materials Available:？
Body: ST37.8 /？A105 /？LF2 /？F304 /？F316. etc.？
Ball: F304 /？F316 (？Option upon request )
Seat: PTFE+C /？Nylon /？PEEK. etc.？
Size DNABLDD1D2
DN 15129642101521.342
DN 20129642301526.742
DN 25159762302033.448
DN 32159852602542.260
DN 40230953003248.376
DN 502301003004060.389
DN 653001593005076.1114
DN 803001703006588.9140
DN 10045019232580114.3185
DN 125450208325100141.3216
DN 150450241350125168.3219
