Structure Introduction
The design and manufacture of this product completely conform to API spec 6A "Wellhead and X-mas Tree Equipment Specification" requirement, which matches and is interchangeable with any parts conforming to API spec 6A specification. This is a non-return valve, which realizes the metal-to-metal seal by the pressure of the medium. The higher the pressure grows the better the sealing effect is. The valve chamber can bear the pressure of the pipeline anytime.
The body of the valve is made of alloy steel forging; therefore, the valve possesses better mechanical properties and reliable property, can bear higher pressure. The cover plate is connected with the valve body with bolts; the seals include the sealing ring in the cover plate and the seal in the body of the valve, which possesses reliable property. The assembly gap between the cover plate and the body is minimized to as little as zero, which reduces the erosion of the bolt and bolt hole by corrosive medium, and the bolt load is reduced as well.
The sealing face between valve core and valve body is overlay welded with hard alloy of good abrasion resistant and anti-corrosion property. The valve is made of sulfur-resistance steel and the other parts adopt the process of hardness limit so that the valve is applicable in the H2S environment.
Operation Introduction
The valve is installed according to the medium flow direction indicated on the valve body. The valve core moves and seals with both up-flowing pressure and down-flowing pressure, therefore, the valve core shall not be stuck.
Maintenance
1,Replace the valve core and sealing piece
Discharge the pressure inside the valve cavity, dismount bonnet bolt, take out the bonnet, take out the valve core and replace a new one. When replacing the valve core, the core and the valve body shall be ground together. Check whether the bonnet sealing ring is in good condition, if not, replace it immediately.
|
NO |
Description |
Quantity |
Material |
Remark |
|
1 |
Valve body |
1 |
35CrMo |
|
|
2 |
Valve clack |
1 |
35CrMo |
|
|
3 |
Spring |
1 |
65Mn |
|
|
4 |
Valve core |
1 |
2CuA19-4 |
|
|
5 |
"O"ring |
2 |
NBR |
|
|
6 |
Valve Bonnet |
1 |
35CrMo |
|
|
7 |
Valve bonnet bolt |
8 |
35CrMo |
|
|
8 |
Valve bonnet nut |
8 |
40Cr |
|
