Exe 2q Series Air Control Solenoid Valve 2q200-25
| Price: |
US $ 7/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
1. Fluid applied: Air, Water, Oil, Gas 2. Action model: Direct Drive Type3. Style: NC style4. Adapter Diameter: 1", 1 1/4", 1 1/2", 2"5. Working pressure: Water: 0~0.7Mpa6. Max pressure: 1.05 Mpa7. Operating Temperature: -5~+100ºC2Q Series Air operated air control valve aperture flow 16mm,20mm,25mm,35mm,40mm,50mm | 2Q | 200 | 20 |
| Type | Aperture Flow Rate | Port size |
| 2Q:2Q Series Two Position Two Way Air Control Valve | 160:16mm | 15:G1/2" |
| 200:20mm | 20:G3/4" |
| 250:25mm | 25:G1" |
| 350:35mm | 35:G1-1/4" |
| 400:40mm | 40:G1-1/2" |
| 500:50mm | 50:G2" |
| Model | 2Q160-15 | 2Q200-20 | 2Q200-25 | 2Q350-35 | 2Q350-40 | 2Q500-50 |
| Working Medium | Air, Water, Oil, Gas |
| Motion Pattern | Direct Drive Type |
| Working Pressure Rang | 0~0.7MPa |
| Max. Pressure Resistance | 1.05MPa |
| Control Pressure Rang | 0.3~0.6MPa |
| (mm)Aperture of Flow Rate | 16 | 20 | 25 | 35 | 35 | 50 |
| CV Value | 4.8 | 12 | 12 | 24 | 29 | 48 |
| Joint Pipe Bore | G1/2" | G3/4 | G1″ | G1-1/4" | G1-1/2″ | G2″ |
| Operating Temperature Rang | -5~+100ºC |
| Material of Body | Brass |
| Material of Oil Seal | PTFE |
| Operation Fluid Viscosity | 50 CST(Below) |
| Control Joint Pipe Bore | 2-M5 | 2-G1/8″ | 2-G1/8″ | 2-G1/4″ | 2-G1/4″ | 2-G1/4″ |
| Prod Model: |
Solenoid Valve 2Q200-25 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO9001:2008 |
| Thread Standard: |
NPT, BSPT, Bsp |
| Export Markets: |
Global |
| Voltage: |
AC110V 220V DC12V 24V |
| Fluid: |
Air, Water, Gas, Oil |
| Style: |
Nc Style |
| Working Pressure: |
0~0.7MPa |
| Port Size: |
1/8",1/4",3/8",1/2",3/4",1" |
| Lead Time: |
15-20 Days |
| Mark: |
Exe |
| Connection Form: |
Thread |
| Type: |
Direct Acting |
| Valve Structure: |
Direct-Acting Piston Structure |
| Application: |
Household Usage |
| Power Supply: |
AC/DC Solenoid Valve |
Ningbo Excellence Automatic Industrial Co., Ltd is a leading pneumatic products manufacturer in China. And our products covers solenoid valve, air source treatment unit, control element and executive element etc, which are widely used in industries such as machinery, textile, food, enviromental protection. Our company posesses all the production capability and capacity to produce from raw material up to the finished product under requirement of ISO9001: 2008 and CE.
This production capability, coupled with R&D incorporating new technologies and know-how, enables us to serve long lasting, reliable products which can expand to a wide range of diversity.
Our goal is supplying the best qualtiy and service through advanced technology to customers.
Welcome to Ningbo Excellence Automatic Industrial Co., Ltd!
