Exe Hv Series Hand Switching Pneumatic Valve Hv-03
| Price: |
US $ 3.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
Product Description 1. HV Series hand switching valve2. Three position Four Way3. Port Size G1/4,G3/8,G1/24. Various handler shape selectable5. Switching angle 90º,sensitive repond acting6. Smooth switching,Long service life| ORDERING CODE |
| HV | 02 |
| Type | Port Size |
| HV:HV Series Three Position Four way Hand Switching Valve | 02:G1/4" |
| 03:G3/8" |
| 04:G1/2" |
| SPECIFICATION |
| Model no | HV-02 | HV-03 | HV-04 |
| Working Medium | Compressed 40 Micron Filtered Air |
| Body Material | Aluminum Alloy |
| Position And Way Numbers | Three Position Four Way |
| Port Size | G1/4" | G3/8" | G1/2" |
| Motion Pattern | Direct Acting |
| Working Pressure | 0~0.8MPa |
| Switching Angle | 90º |
| Operating Temperature | 0~70ºC |
| Prod Model: |
Hand Switching Pneumatic Valve HV-03 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO9001:2008,CE,RoHS |
| Thread Standard: |
NPT, BSPT, Bsp |
| Export Markets: |
Global |
| Voltage: |
AC110V 220V DC12V 24V |
| Fluid: |
Air, Water, Gas, Oil |
| Function: |
Change The Flow Direction |
| Mark: |
Exe |
| Port Size: |
1/8",1/4" |
| Way: |
2position 4 Way |
| Lead Time: |
15-20 Days |
| Connection Form: |
Thread |
| Valve Structure: |
Direct-Acting Piston Structure |
| Application: |
Household Usage |
| Type: |
Hand Draw |
| Material: |
Aluminum Alloy |
| Power Supply: |
AC/DC Solenoid Valve |
Ningbo Excellence Automatic Industrial Co., Ltd is a leading pneumatic products manufacturer in China. And our products covers solenoid valve, air source treatment unit, control element and executive element etc, which are widely used in industries such as machinery, textile, food, enviromental protection. Our company posesses all the production capability and capacity to produce from raw material up to the finished product under requirement of ISO9001: 2008 and CE.
This production capability, coupled with R&D incorporating new technologies and know-how, enables us to serve long lasting, reliable products which can expand to a wide range of diversity.
Our goal is supplying the best qualtiy and service through advanced technology to customers.
Welcome to Ningbo Excellence Automatic Industrial Co., Ltd!
