Exe Solenoid Valve Direct Acting Plastic Water Valve 2p025-08
| Price: |
US $ 5.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
2P025 Series solenoid valve adopts engineering plastic as its body, both of solid metal material properties and the toughness of the plastic . At thesame time reducing the manufacturing cost, light body, has the rich selection of voltage, wattage low standard voltage. Providing a very good choice for small fluid application Media: Air, water, oil Temperature: -5 C~180 C Body:Plastic Acting Type:Drection Orifice (mm): 2.5~50 Seal: PNBR,EPDM,VITON Features: 1. Integral slot piston structure2. Process valve hole with special high precision finishing process3. Beautiful appearance4. Good reverser5. Reliable performance6. Seal wear can automatic compensate| Model | 2P025-06 | 2P025-08 |
| Fluid | Air |
| Action | Direct acting type |
| Type | Normally closed type |
| Effective area (Square meters) | 1.2 |
| CV Value | 0.23 |
| Port Size | 1/8 | 1/4 |
| Viscosity Limit | Under 20 CST |
| Operating Pressure | 0-8.0kgf/ Square meters |
| Proof Pressure | 10kgf/Square meters |
| Ambient & fluid temperature | ' -5~60 degree centigrade |
| Voltage range | ±10% |
Mainparts material Body
Seal | Aluminum Alloy |
| NBR |
| Prod Model: |
Water Valve 2P025-08 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO9001:2008 |
| Thread Standard: |
NPT, BSPT, Bsp |
| Export Markets: |
Global |
| Voltage: |
AC110V 220V DC12V 24V |
| Fluid: |
Air, Water, Gas, Oil |
| Fluid Pressure: |
0~0.7MPa |
| Port Size: |
1/8" , 1/4" |
| N/C Or N/O: |
Normally Closed |
| Lead Time: |
15-20 Days |
| Mark: |
Exe |
| Connection Form: |
Thread |
| Type: |
Direct Acting |
| Valve Structure: |
Pilot Membrane Structure |
| Power Supply: |
AC Solenoid Valve |
| Application: |
Household Usage |
| Material: |
Plastic |
Ningbo Excellence Automatic Industrial Co., Ltd is a leading pneumatic products manufacturer in China. And our products covers solenoid valve, air source treatment unit, control element and executive element etc, which are widely used in industries such as machinery, textile, food, enviromental protection. Our company posesses all the production capability and capacity to produce from raw material up to the finished product under requirement of ISO9001: 2008 and CE.
This production capability, coupled with R&D incorporating new technologies and know-how, enables us to serve long lasting, reliable products which can expand to a wide range of diversity.
Our goal is supplying the best qualtiy and service through advanced technology to customers.
Welcome to Ningbo Excellence Automatic Industrial Co., Ltd!
